Lenze I95AE222F

Connecon diagr
am and shield connecon
Connect all shields with a large surface and x it with c
able es or xing clips.
Connecon diagr
am HIPERFACE DSL® (OCT) Shield connecon
EYP008xxxxxxM1xA00
M 3~
GB
24B
DC 24 V SELV/PELV
(+19.2 V ... +28.8 V)
BD2 BD1
bk
1
bk
2
bk
3
bk
5
+
bk
6
-
wh
+DSL
bl
-DSL
gnye
-
+
X105
X109
X107
X106
↑
Electrical ins
tallaon
Connecon of one cable technology (OCT) via HIPERFACE DSL®
157
