BA 12.0023−EN 6.0
Pos. Contents
1 Production site
2 Motor type / standard
3 Gearbox type
4 Motor type
5 Technical data
Ratio
Rated torque
Rated speed (rated frequency)
6 Mounting position / position of the system modules
7 Lubricant
8 Brake data (if fitted)
Type
AC/DC brake voltage
Braking torque, electrical power consumption
9 Feedback /pulse encoder or resolver data (if fitted)
10 Production data
Order number
Material number
Serial number
Additional customer data
11 Bar code
12 Rectifier identifier
13 Information on operating mode
14 Additional information on
motor
Thermal class
Degree of protection
Motor protection
15 Applicable conformities and approvals
16 Rated data for 5
0 Hz, 60 Hz and 87 Hz
Hz = output frequency
kW = motor power
HP = motor power Horsepower
r/min. = motor speed
V = motor voltage
A = motor current
h = motor efficiency
cos j = motor power factor
C 86 = Code 0086, selection code for operation on servo inverter
17 Application factor (data if < 1.0)
18 Year of manufacture/ week of manufacture
19 Additional information
20 ALR = Ampere locked rotor
21 Inverter duty motor PWM
