7.2.6 Amount of lubricant for combined mounting positions
For the gearbox sizes 03 ...05 a combination of different mounting positions with amounts
of lubricant to suit are permissible as per the following tables.
Advantage:
Easier logistics for users who use gearboxes in different mounting positions.
Disadvantage:
On some gearboxes more lubricant is necessary in the gearbox than is necessary
technically. As a result a higher internal pressure is produced.
Helical gearbox GST03 ... 05−2; VLL
Versions VLR; VLL
Mounting position GST03 GST04 GST05
A E F
0.20
0.35 0.7
B C 0.50 0.85
D 0.55 1.0
Version VLK
A E F
0.17
0.35 0.55
B C 0.45 0.7
D 0.6 0.95
Shaft−mounted helical gearbox GFL04 ... 05−2; VLL
Versions VLR; VLL
Mounting position GFL04 GFL05
A B E 0.7 1.4
C D 1.0 1.7
F 0.3 0.7
Version VLK
A B E 0.8 1.4
C D 1.1 1.7
F 0.35 0.7
Helical−bevel gearbox GKS04 ... 05−3; VLL
Versions VLR; VLL
Mounting position GKS04 GKS05
A 0.8 1.3
B C E F 1.4 2.0
D 1.0 1.6
Version VLK
A 0.8
1.4
B C E F 1.5 2.1
D 1.1 1.7
