Electrical installation
Motor connection
5
l
50
BA 12.0023−EN 6.0
5 Electrical installation
{ Danger!
Electrical connections must only be carried out by skilled personnel!
5.1 Motor connection
To correctly connect the motor, please observe:
ƒ the notes in the terminal box of the motor
ƒ the notes in the Operating Instructions of the motor
ƒ the technical data on the motor nameplate.
5.2 Motor options
To correctly connect the motor options, e. g. brakes or feedback systems, please observe:
ƒ the notes in the corresponding terminal box
ƒ the notes in the corresponding operating instructions
ƒ the technical data on the corresponding motor nameplate.
