Lenze L−force GST - Page 61

Maintenance
Maintenance operations
Lubricant quantity
7
l
61
BA 12.0023−EN 6.0
Helical gearbox GSTLL−1L VAL / VBL (foot housing)
Mounting
position
A B C D E F
GST04
0.1 0.37 0.2 0.3
0.35 Ww1C
0.25 0.25
GST05
0.2 0.6 0.35 0.5
0.6 Mw90
A w80
Nw1D
0.35 0.35
GST06
0.4 1.2 0.65 0.85
1Ww1E
0.7 0.7
GST07
0.7
1.3 Mw132
Aw112
Nw1G
Ww1G
2.3
2.7 Mw132
Aw112
Nw1G
Ww1G
1.3 1.5
2.2 Mw132
Aw112
Nw1G
Ww1G
1.5 1.5
GST09
1.2
2.5 Mw132
Aw112
Nw1G
Ww1G
4.1
4.8 Mw132
Aw112
Nw1G
Ww1G
2.8 2.7
3.7 Mw132
Aw112
Nw1G
Ww1G
2.5 2.5
Helical gearbox GSTLL−1L VCL (flange housing)
Mounting
position
A B C D E F
GST04
0.1 0.3 0.15 0.3
0.35 Ww1C
0.2 0.2
GST05
0.2 0.5 0.2 0.45
0.55 Mw90
A w80
Nw1D
0.3 0.3
GST06
0.4 1 0.45 0.85
1Ww1E
0.6 0.6
GST07
0.8
1.5 Mw132
Aw112
Nw1G
Ww1G
1.6
2.0 Mw132
Aw112
Nw1G
Ww1G
0.85 1.6
2.3 Mw132
Aw112
Nw1G
Ww1G
1.3 1.3
GST09
1.6
2.7 Mw132
Aw112
Nw1G
Ww1G
3.0
3.5 Mw132
Aw112
Nw1G
Ww1G
1.7 2.7
3.7 Mw132
Aw112
Nw1G
Ww1G
2.3 2.3
Tab. 10 Amount of lubricant in litres
W
Drive 90...132 Motor size
A, M, N, W Drive−end version 1A ...2K Drive size
