EDKLCMZ3024−SPS DE/EN 4.0
Status display: device
lcu121_000g
Pos. Colour Status Description
ERR red
off No fault
flashing Active fault
RUN green
on Device enabled
flashing Device inhibited
BRK green
on Brake open
off Brake closed
STOP green
on Safe torque off (STO) active
off Safe torque off (STO) inactive
SERV green
on Device in normal operation
off Device not ready for operation (service)
ONLINE green
on Fieldbus online
off Fieldbus offline
IN1 green
on I1 = HIGH
off I1 = LOW
IN2 green
on I2 = HIGH
off I2 = LOW
IN3 green
on I3 = HIGH
off I3 = LOW
IN4 green
on I4 = HIGH
off I4 = LOW
OUT1 yellow
on Q1 = HIGH
off Q1 = LOW
OUT2 yellow
on Q2 = HIGH
off Q2 = LOW
Status display: fieldbus interface
lcu121_000h
Pos. Colour Status Description
Status GG green
on Motor starter is supplied with voltage.
off Motor starter is not supplied with voltage.
flashing Motor starter is being initialised
Status FB yellow
off No communication with the PROFIBUS master
flashing Communication with the PROFIBUS master has been built up.
