EDKLCMZ3024−SPS DE/EN 4.0
Status display: drive−based safety
lcu121_000h
Pos. Colour State Description
MS Green
on
Integrated safety technology has been properly initialised.
off Integrated safety technology has not been initialised.
Confirmation is not possible.
EN Yellow
On
Controller enabled
Off
Non−safe display "STO"
ME Red
On
System error:
l After a serious internal error STO is activated.
l Reset is only possible by switching the 24−V supply.
Blinking
Error:
l After an internal error or an error on the sae inputs or outputs, STO
is activated.
l The safety class is exited.
l Confirmation is possible.
Off Error−free operation
PS Red
On
Error PROFIsafe:
l Communication is not possible.
l Acknowledgement is possible.
Blinking
No valid PROFIsafe configuration
Off PROFIsafe is error−free.
SI1 green
on Channels A and B are ON
off At least one channel is OFF
SI2 green
on Channels A and B are ON
off At least one channel is OFF
SI3 green
on Channels A and B are ON
off At least one channel is OFF
SI4 green
on Channels A and B are ON
off At least one channel is OFF
SO1 yellow
on Channels A and B are ON
off Channels A and B are OFF
SO2 yellow
on Channels A and B are ON
off Channels A and B are OFF
