This documentation is valid for ...
... ELCAM... motor starters as of nameplate designation:
Nameplate
ELC A M Z I xxx x S NN PS NN 1C 30
Product series
LCU
Version
A = 1st generation
Type
M = motor starter
Variant
E = one motor, one direction of
rotation
Z = two motors, one direction of
rotation
W = one motor, two directions of
rotation
Mechanical version
I = housing in high enclosure IP54
Rated power [W]
e.g.
751 = 75 x 10
1
W = 750 W
152 = 15 x 10
2
W = 1.5 kW
Voltage class
lcu12x_002
2 = 230 V AC
4 = 400 V AC
Safety function
A = without safety functions
S = with drive−based safety
Communication
PM = PROFIBUS−DP−V0
PS = PROFIBUS−DP−V0, PROFIBUS−DP−V1, PROFIsafe
Hardware version
Px = prototype, version x
1C = series, version C
Software version
12 = software 1.2
22 = software 2.2
