Lenze m500-P Series

About this documentation
Document history
1
5
Lenze ¯ BA 33.0008 ¯ 5.0
1 About this documentation
Contents
¯ The present documentation is intended for safe working on and with the drives. It
contains safety instructions that must be observed.
¯ All persons working on and with the drives must have the documentation at hand
during work and observe the information and notes relevant for it.
¯ The documentation must always be complete and in a perfectly readable state.
If the information and notes provided in this documentation do not meet your
requirements, please refer to the gearbox documentation.
I Tip!
Information and tools concerning the Lenze products can be found in the
download area at
www.lenze.com
Validity
This documentation is valid for three−phase AC motors:
Type Name
m500−P
m540−P
m550−P
Three−phase AC motors (squirrel−cage induction motor)
Target group
This documentation is directed at qualified skilled personnel according to IEC 60364.
Qualified skilled personnel are persons who have the required qualifications to carry out
all activities involved in installing, mounting, commissioning, and operating the
product.
1.1 Document history
Material number Version Description
13493941 1.0 06/2015 TD09 First edition for the pilot series
.ZCq 5.0 05/2019 TD09 Extended by: 0.75kW; motor, B14 type and sizes
080...112
Supplementation of the approvals and Appendix
chapter
Change of the starting torques and power
terminals
.ZCq 5.0 05/2019 TD09 Extended by m54AP motor
13536578 4.0 06/2017 TD09 "Technical data in compliance with ordinances
"(EU) No. 4/2014 or (EC) No. 640/2009" table
changed
.ZCq 5.0 05/2019 TD09 Chapter: Electrical installation − brake
connection, contact identifications have been
added
