Technical data
General data and operating conditions
4
19
Lenze ¯ BA 33.0005 ¯ 5.0
Operating conditions
Ambient conditions
Climatic
Transport IEC/EN 60721−3−2 2K3 (−20 °C ... +70 °C)
Storage IEC/EN 60721−3−1
1K3 (−20 °C ... +60 °C) < 3 months
1K3 (−20 °C ... +40 °C) > 3 months
Operation IEC/EN 60721−3−3
3K3 (−20 °C ... +40 °C)
MCA, MCS, MDKS
Without brake
3K3 (−15 °C ... +40 °C)
MCM, MQA
3K3 (−10 °C ... +40 °C)
With brake
3K3 (−15 °C ... +40 °C)
With blower
> +40 °C With power reduction, see
catalogue
Site altitude < 1000 m amsl − without power reduction
> 1000 m amsl < 4000m amsl with power reduction, see
catalogue
Humidity Relative humidity £ 85 %, without condensation
Electrical
The motor connection type depends on the controller
Length of the motor cable
inverter instructions
Length of cable for speed feedback
Mechanical
IEC/EN60721−3−3 3M6
