Lenze MSEMA Series - The Modular System

The modular system
Gear
ed motors up to 75 Nm
Gearbox g350-B25 g350-B50 g350-B75
Motor MSEMA☐☐063-42 MSEMA☐☐063-42 MSEMA☐☐080-32
Technical data
Max. output torque Nm 25 50 75
Rated torque Nm 19.3 19.3 55.2
Output speed rpm 42.6 ... 221.2
Mounng
posion Universal
Colour Unpainted
Surface and corrosion protecon Without
gearbox data
Gearbox g350-B25 g350-B50 g350-B75
Dimensions
Hollow sha with keyway mm 16 20 20
Product extensions
Solid sha with featherkey mm 16 x 40 20 x 40 20 x 40
Output ange mm FT65/FF100 FT87/FF100 FT100/FF130
Torque plate Can be mounted on the threaded pitch circle of the housing
Gearbox version With centering (HCR)
Lubricant CLP HC 220 USDA H1
(Synthec oil, suitable for the food industry)
Motor data
Motor MSEMA☐☐063-42 MSEMA☐☐080-32
Conformity CE, EAC
Approval CCC, cULus
Cooling Integral fan
Degree of protecon
EN 60529 IP55
NEMA 250 Type 4 indoor only
T
ype 12
Motor connecon
Power connecon QUICKON connector
Control connecon M12 connector
Brake
Without spring-applied
brake
Without brake resistor
With spring-applied brake Brake type: Standard
Brake resistor: Integrated
Brake type: Standard
Brake resistor: External
Feedback Without
Temperature monitoring Internal
Monitoring and protecve
measures
Short circuit (to a limited extend), fault acknowledgement
Earth fault (to a limited extent), fault acknowledgement necessary
Overvoltage
Overcurrent
Motor overtemperature
Mains phase failure
Protecon in the event of cyclical power-supply switching
Motor stalling
Product informaon
The modular system
