Lenze MSEMA Series - Torque Plates; Torque Plate on Threaded Pitch Circle

Torque plates
T
orque plate on threaded pitch circle
Torque support is usually provided by means of the ange.
The torque plates that can be ed are another simple possibility. In this case, torque support
is provided only via one point and is suitable for sha-mounted gearboxes, among other
things. Integrated rubber buers ensure stress-free installaon and absorb any slight impacts.
Mounng is carried out with the help of four bolts in dierent posion on the housing.
Torque plate
Gearboxes VPE Order code
Piece
g350-B25 1 13518585
g350-B50 1 13518588
g350-B75 1 13518589
Product extensions
Mechanic
al extension
Torque plates
