Technical data
General data
4
EDK82ZAFPC−001 DE/EN/FR 7.0
45
H1_Daten−IP20
4 Technical data
General data
Field Values
Order designation E82ZAFPC001
PUO ID number 0x00DA
hex
Communication profile
(DIN 19245 part 1 and part 3)
PROFIBUS−DP−V0
Communication medium RS485
Drive profile "Drive technology 20" DRIVECOM profile, can be switched off
Network topology
l Without repeater: line
l With repeater: line or tree
PROFIBUS nodes Slave
Baud rate [kbps] 9.6 ... 12000 (automatic recognition)
Process data words 1 ... 10 words
(16 bits per word)
DP user data length 4 parameter data words +
1 ... 10 process data words
Max. number of nodes
l Standard: 32 (= 1 bus segment)
l With repeater: 125
Max. cable length per bus
segment
1200 m (depending on the baud rate and cable type used)
External DC voltage supply +24 V DC ±10 %, max. 80 mA
Operating conditions
Ambient conditions
Climate
Storage
IEC/EN 60721−3−1 1K3 (−25 to +60 °C)
Transport IEC/EN 60721−3−2 2K3 (−25 to +70 °C)
Operation Corresponding to the data of the Lenze standard device used (see
documentation of the standard device).
Pollution EN 61800−5−1 Degree of pollution 2
Degree of protection IP20 (protection against accidental contact according to NEMA 250 type 1)
