6 Electrical installation
Wiring to a host
EDK82ZAFPC−001 DE/EN/FR 7.0
52
H2 VerdrahtLeitrechner−PBS_leitungsspezifikation
Specification of the transmission cable
Note!
Only use cables complying with the listed specifications of the PROFIBUS user
organisation.
Field Values
Specific resistance
135 ... 165
W/km, (f = 3 ... 20 MHz)
Capacitance per unit length
£ 30 nF/km
Loop resistance
< 110 W/km
Core diameter > 0.64 mm
Core cross−section > 0.34 mm
2
Cores Twisted double, insulated and shielded
