KRTM 3B… - 08 2016/11
Switching threshold diagrams
Static 2-point teach
Dynamic 2-point teach
Static 1-point teach
Label with marks
1. Teach point on background 2. Teach point on mark
Switching threshold in center
Receive signal
Switching output for switching threshold
in center
Switching output for switching threshold
near the mark
Switching threshold near the mark
Label with marks
Open measurement window Close measurement window
Switching threshold in center
Receive signal
Switching output for switching threshold
in center
Switching output for switching threshold
near the mark
Switching threshold near the mark
Label with marks
Teaching reference value
Standard sensitivity
Receive signal
Switching output for standard
sensitivity
Switching output for high sensitivity
High sensitivity
KRTM 3B
