Intended use
The ultrasonic forks for splice inspection are ultrasonic sensors for the contactless
detection of splices on paper, film or plastic webs.
NOTICE
Observe intended use!
This product is not a safety sensor and is not intended as personnel
protection.
Ä Only allow competent persons to put the product into operation.
Ä Only use the product in accordance with its intended use.
Function and device operation
For reliable detection of the splices, the web must be slightly tensioned on the
lower fork.
– Light switching: signal on the splice.
– Dark switching: signal on the web.
Overview of the operating structure via the teach and minus buttons
Function Configuration via buttons
Standard function Normal operation after switch-on
easyTeach
(with or without web transport)
Press the teach(+) button: 2…7s
Setting the pulse stretching Press the teach(+) button: 7…12s
Set switching behavior
(light/dark switching)
Press the teach(+) button: >12s
easyTune function – Manual fine tuning
of the switching threshold
Increase sensitivity
Reduce sensitivity
Press the teach(+) button: <2s
Press the minus(-) button: <2s
Manual locking/unlocking of the buttons
on the device
Simultaneously press the teach button
(+) and the minus button (-): > 7 s
