Leuze IGSU 14E SD - Pulse Stretching and Switching Behavior

Setting the pulse stretching
If the web speed is high and the splice width is thin, the signal on the switching
output is very short when moving over a splice.
– Therefore a fixed pulse stretching of 20ms is activated in the factory set-
tings.
– If pulse stretching is undesirable, you can switch the function off.
3
Ä Press the teach button until the green ONLED and the yellow OUTLED flash
alternately.
Ä Release the teach button.
ð The green ONLED flashes for another 2 seconds and the yellow OUTLED
indicates the changed status of the pulse stretching for 2 seconds:
OUTLED ON: pulse stretching activated
OUTLED OFF: pulse stretching deactivated
Adjusting the switching behavior of the switching output (light/dark
switching)
4
Ä Press the teach button until only the green ON LED flashes.
Ä Release the teach button.
ð The green ONLED flashes for another 2 seconds and the yellow OUTLED
indicates the changed switching behavior for 2 seconds:
Yellow OUTLED ON: switching output, light switching (signal on the splice)
Yellow OUTLED OFF: switching output, dark switching (signal on the web)
