LevelOne FBR-1161 - Front Panel

7
2.3. Front Panel
LED
Description
PPP
Lit steady when there is a PPPoA / PPPoE connection.
ADSL
Lit when successfully connected to an ADSL DSLAM (“linesync”)
USB
Lit when the USB port is connected to the PC and working properly
LAN
Lit when connected to an Ethernet device.
Green for 100Mbps; Orange for 10Mbps.
Blinking when data is Transmitted / Received.
SYS
Lit when the system is ready.
PWR
Lit when power is ON.
