LED Behavior
Function LED Behavior Description Remark
Status
Hardware
failure
Front Left
(Green)
Status
Steady On
1. Restoring
settings
2. Normal
Operation
Front Left
(Green)
Status
Unlighted
1. Power Off
2. Power On
till System
setup
The LED
can be
configured
to be
unlighted
during
normal
operation
Status
While F/W
upgrading
Front Left
(Green)
Link
Blinking
Blinking while
network
connection in
progress
Rear Left
(Orange)
Link
Unlighted
No connection Rear Left
(Orange)
Power
Steady On
Normal
Operation
Rear Right
(Green)
Power
Unlighted
Power off Rear Right
(Green)
