Hardware Manual
12
Step 2: Open the Dome Cover
NOTE: To avoid scratches or leaving fingerprints on the dome cover, it is recommended to retain
the plastic covering the dome cover until the camera is completely installed. However, the plastic
has been removed on the pictures in this documentation to show clarity of the procedures being
described.
1. If the cables will pass through the surface, remove the metal cap covering the bottom conduit
hole of the camera, and attach the cap to the side hole to close it. The cable(s) will be routed
to pass this hole from the surface.
2. Loosen the three (3) screws securing the dome cover.
