3. Connect the other end of the network cable to a switch or injector. Then, connect the switch
or injector to a network or PC and a power source. See Power-over-Ethernet (PoE) example
connection diagram below.
Network
AC Power
Source
PoE Injector /
PoE Switch
Power Cable
Ethernet Cable
Ethernet Cable
(Data + Power)
Ethernet Cable
(Data)
Camera
Step 6: Access the Camera Live View
See Accessing the Camera on page 35 for more information on how to access the Live View of
the camera.
Step 7: Adjust the Viewing Angle
Based on the live view, adjust the viewing angle and orientation of the camera. Adjustments vary
per model. For detailed information, please refer to How to Adjust the Viewing Angle on page
30.
