4.2.1 Conguring Electrical Components Using Power Meter Viewer Utilities
1. Navigate to Meter Setup under the Display Menu List Box.
2. Enter a System Description for the physical location of the meter.
3. Enter Element Description (defaults are A, B, etc.).
4. Select the Voltage Input (voltage connector 1 or 2) - for OS48 only.
5. Select the Voltage Multiplier (optional).
6. Select the Service Type (3-Phase 4-Wire, etc.).
7. Select CT Type (HSC-050, etc.).
8. Set CT Multiplier (optional).
9. Set CT Flipper (optional).
10. Repeat steps 3 - 7 for each Element.
11. Click SEND SETUP TO METER.
