4.2.2 Conguring RS-485 Communications Using Power Meter Viewer Utilities
If planning to setup communication via RS-485, follow the steps below:
1. Navigate to Communication Setup under Display Menu List Box.
2. Select RS-485.
3. Select either Modbus or BACnet.
If you selected Modbus, set the following:
• Serial Settings
• Set Modbus Address
If you selected BACnet, set the following:
• Serial Settings
• Device ID
• MS/TP Address
• Max Masters (optional)
• Max Info Frames (optional)
4. Click SEND SETUP TO METER.
