4.2.3 Conguring Ethernet Communications Using Power Meter Viewer Utilities
If planning to setup communication via Ethernet, follow the steps below.
1. Navigate to Communication Setup under the Display Menu List Box.
2. Select Ethernet.
3. Select either Modbus or BACnet.
4. If you selected Modbus, set the following:
Modbus Port (optional)
If you selected BACnet, set the following:
• Device ID
• BACnet Port and BBMD
5. Select either DHCP or Static IP.
6. If you selected DHCP, proceed to the next step.
If you selected Static IP, set the following:
• Static IP Address
• Subnet Mask
• Gateway Mask
• Default Gateway
7. Click SEND SETUP TO METER.
