2 Wire, 1 Phase
(Plug Load)
Service Type 3
V_Input 1 or 2
Description
31 Char
Channels Volt Ref CT Type Range Phase Shift CT Multiplier CT Sign
CH1 ANY [1-6] mV [1] or RoCoil [2] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
CH2 ANY [1-6] mV [1] or RoCoil [2] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
CH3 ANY [1-6] mV [1] or RoCoil [2] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
3 Wire, 1 Phase
(Split Phase)
Service Type 4
V_Input 1 or 2
Description
31 Char
Channels Volt Ref CT Type Range Phase Shift CT Multiplier CT Sign
CH1 L1 – N [1] mV [1] or RoCoil [2] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
CH2 L2 – N [2] mV [1] or RoCoil [2] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
CH3 L3 – N [3] OFF [0] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
Disabled (OFF)
Service Type 5
V_Input 1 or 2
Description
31 Char
Channels Volt Ref CT Type Range Phase Shift CT Multiplier CT Sign
CH1 L1 – N [1] OFF [0] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
CH2 L2 – N [2] OFF [0] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
CH3 L3 – N [3] OFF [0] Any > 0A -3.0˚ to +3.0˚ Any > 0 [1] 0 or 1
If any channel needs to be turned OFF, set the CT Type to OFF.
Even though CH3 is not used for computation, it is recommended that
the CT settings reect those from CH1 rather than left at the factory
default settings to facilitate conguration validation from the RTU.
Even though disabled channels are not used in calculations and
report 0.0, they still contain conguration information. It is suggested
that they be set to a known value, rather than left at their factory
default settings to facilitate conguration validation by the RTU.
7 RTU PROGRAMMING AND SCRIPTING
