Leviton Series 2000 - Table 2: Series 2000 Electrical Specficiation; Table 2 - Series 2000 Electrical Specifications

2 TECHNICAL SPECIFICATIONS
8
Series 2000 Electrical Specifications
Input Configurations 3Phase, 4 Wire (120/208V or 277/480V)
Supply Voltage Range (Line to Neutral) 102-138VAC
235-320V
AC
Maximum Input Power 7VA
Maximum Rated Current Primary: Max Operating Current + 10%
Secondary: 0.12A
Line Frequency 60Hz
Power Factor Range 0.5 to 1.0 Leading or Lagging
Accuracy
1
+/- 0.5% of registration @ 1.0 PF, 1% to 100%
of rated current
+/- 0.75% of registration @ 0.5 PF, 1% to 100%
of rated current
Meter Operating Temperature -30 to 60° C
Display Operating Temperature -20 to 50° C
Rated Pollution Degree
2
2
Rate Relative Humidity 80%
Terminal Block Torque Ratings:
Voltage Terminal
CT and I/O Terminal
12 in-lb max
4.4 in-lb max
Table 2 - Series 2000 Electrical Specifications
1
Accuracy based on Leviton solid core current transformers (included), with 100 mA secondary output.
Meter input burden resistance at 2 Ohms
2
Pollution Degree 2: Normally only non-conductive pollution occurs. Occasionally, however, a temporary
conductivity caused by condensation must be expected.
