State “Off”:
The pump system is switched off and the motor phases have no power (current). The Setpoint Speed can be
modified with the Up and Down buttons, without any effect on the system states.
State “On (Speed Control)”:
This state can be reached by manually activating the system with the On/Off button. The impeller is levitating
and rotating with the Setpoint Speed, which can be manually adjusted with the Up and Down buttons. The
motor has electrical power when in this state.
State “On (Controlled by PLC)”:
This state can be reached by activating the digital input on the PLC connector (see Table 8). The pump
system is switched on and the impeller is levitating and rotating with the Setpoint Speed, which is adjusted
with the current of the analog input (see Table 8).). The motor phases have electrical power when in this
state.
State “Error”:
If an error occurs, the system switches to the Error state. The pump system is disabled. The system switches
back to the “Off state by pushing the On/Off button or by a pulse of 300-700ms on the digital input of the
PLC interface (see Table 8).
“Menu”:
The Menu is not a system state, but an additional tool to modify the system setup or to display system
information. From any system state, the menu is reached pushing the On/Off button for more than 4 seconds
and left by pushing it for more than 2 seconds. The following menu points are available:
Menu Tab 1: Set Timer
A timer can be set, which stops the pump, when expired. The timer can either be set as single
or repetitive timer. The values are selected with the On/Off button, and modified with the Up and
Down button.
Menu Tab 2: System Information
For trouble shooting useful information can be read like driver temperature, axial impeller
position, and DC-link voltage (supply).
Menu Tab 3: System Information
For trouble shooting useful information is shown like drive (DRV) and bearing (BNG) currents.
Menu Tab 4: Errors, Warnings and Messages
Shows errors, which stop the system, warnings, which might stop the system and messages,
which might be useful for proper operation.
Menu Tab 5: History of Errors, Warnings and Messages
Shows the history of error, warnings and messages, which is useful for troubleshooting.
Menu Tab 6: Firmware Information
Shows the firmware version.
