Figure 4.10
Figure 4.11
Figure 4.12
Figure 4.13
f. Remove the float from the base
chamber by pulling up one
end of the float Figure 4.11 and
pulling the shaft out from the float
brackets. One side of the float
brackets is open (U-shaped) to
allow the shaft to be removed.
Figure 4.12
e. Flip the tank over and remove
the noise silencer. To remove the
noise silencer, press the release
tabs and gently pull away from the
humidifier. Figure 4.10
g. Place the float, water filter
assembly, and noise silencer in a
small container. Fill with enough
vinegar to cover them. Soak for
1520 minutes. Figure 4.13
d. Remove the tank, remove the tank
cover, and pour out any vinegar.
Figure 4.9
Cleaning (cont.)
Figure 4.9
EN
17
