Thank you for purchasing LEVOLOR
®
Cellular Shades. With proper installation, operation,
and care, your new cellular shade will provide years of beauty and performance. Please
thoroughly review this instruction booklet before beginning installation.
MOUNTING TYPES AND WINDOW TERMINOLOGY
Molding
Head Jamb
Sill
Jamb Jamb
Outside Mount
Inside Mount
Molding
Head Jamb
Sill
Jamb Jamb
Outside Mount
Inside Mount
Molding
Head Jamb
Sill
Jamb Jamb
Inside Mount
• Shade fits within
window opening.
• Great for windows
with beautiful trim.
Window Components
Terminology
• Collectively, the sill
and jambs are called
the “window casement”
or “frame”.
Outside Mount
• Shade mounts
outside window
opening.
• Increased light
control and privacy.
Shim–A thin strip of material used to align parts to make them fit.
Minimum Depth Requirements for Proper Shade Installation (inches)
Operating System
Minimum
Mounting Depth
Minimum Depth for
Fully Recessed/Flush
Mount Headrail
Motorized
1
1
⁄4 2
1
⁄4
WINDOW AND SHADE TERMINOLOGY
3Cellular Shades Motorized Control Lift
