Lewmar 140 - Installing Extra Control Panels; List of Spare Parts

Lewmar Swing Thruster Product and Installation Manual ref 500146 iss.3 | 13
List of parts
PART NO DESCRIPTION
58990001 Touch panel
58990002 Joystick panel
68001027 Foot switch
58991003 Control cable 10m to main switch
58992003 Water detector
58992001 Remote control for Swingthruster and anchor windlass
589150 Anode, 140
589350 Anode, 185
589550 Anode, 250
559018 Drive shear pin for model 140
559017 Drive shear pin for model 185
589151 140 propeller
589351 185 propeller
589552 250 propeller, starboard
589551 250 propeller, port
Installing an extra panel
The control panels can be installed in parallel, in which case they will both indicate alike.
When the system is activated from one panel, the system starts with both panels active.
