Venta
TM
Pontoon
Anchor Winch
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0007416
LetterLetter PNPN DescriptionDescription
A 2022375378 Composite drum
B 2023041350 Rope / chain rode with sensor
clasps
C 2022373342 Bearing support
D 2022373347 Chute cover
E 2022373349 Drum Bearing
F 2022375378 Motor gearbox
G 2023032311 Rope guide with chain sensor
H 2022448705 Slack line sensor
I 2023025031 Chain sensor clasp
Not
Pictured
2022453745 Fixing hardware kit containing:
• 6x M8 Cap head screws
• 6x M8 Button head screws
• 12x M8 Nyloc nuts
• 24x M8 Washers
• 4x Cable ties
Not
Pictured
n/a 5m (16’) controller to switch
harness
Parts List
NOTE: Part numbers are shown for identification
purposes only. Not all parts are available for individual
sale. All parts with a link to the Lippert Store can be
purchased.
A
B
C
E
F
H
G
D
Specifications
Product Dimensions
25.4cm
(10”)
50.8cm (20”)
Additional Components Required for Installation
and Operation
A bow-roller and anchor are required for operation of the
Venta
™
winch and must be purchased separately. The
following tables suggest a compatible bow roller and
compatible anchors.
Part #Part # DescriptionDescription
2022375783 Pontoon Bow Roller
2023049445 Pontoon Extendable Bow Roller
30.5cm
(12”)
Part #Part # DescriptionDescription
2020329216 5.5kg (13lbs) Short Shank Delta Style
Anchor (Galvanized)
2020221486 6kg (14lbs) Short Shank Epsilon Style
Anchor
Compatible Bow Roller
Compatible Anchors
I
