lippert.com 432-LIPPERT (432-547-7378) Rev: 10.20.23
Venta
TM
Pontoon
Anchor Winch
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0007416
Installation
A pontoon bow roller and anchor are recommended
for use with the Venta
™
winch. For best results, bow
roller part number 2022375783 or extendable bow roller
part number 2023049445 and anchor part number
2020329216 are designed specifically to work together
for trouble-free deployment and anchoring with the
Venta
™
winch.
Resources Required
• Electric drill
• 8.5mm (⁄”) drill bit
• 5.5mm (⁄ ”) drill bit
• Crimping tool
• Painter’s tape
• 25mm (1”) drill or hole
saw
• 70mm (2 ¾”) drill or hole
saw
• Jig saw
• Flat head screwdriver
(medium)
• Allen wrench/hex key
• Adjustable wrench
• 6mm allen/hex key
• 5mm allen/hex key
• 4mm allen/hex key
• Four #6 (⁄”) screws
• Hand file or sandpaper
• Suitable electrical cable
and crimp terminals (see
the Wiring section of this
manual)
To facilitate the winch and bow roller beneath the deck
of the boat it may be necessary to use a mounting plate.
This plate will bolt to the lateral aluminum structural
beams.
There are several options for installing the winch and
bow roller depending on the setup of the vessel. It may
be installed directly to the deck itself (if the deck has the
requisite thickness of 10mm), a mounting plate, or the
lateral aluminum structural beams of the vessel. Follow
the appropriate instructions guidelines in this manual for
your vessel’s setup.
Installing the Winch and Bow Roller Directly to
Decking or a Mounting Plate
The deck must be at and a minimum of 10mm (.39”)
thick for proper mounting.
If the deck is not thick enough or at, a suitable
mounting plate is required to take up camber or sheer.
This mounting plate must bolt to the lateral aluminum
structural beams and be a minimum of 10mm (.39”) thick.
This will act as the decking. It is recommended that
one plate be used for both the winch and the bow roller.
Double check the length of the intended plate to make
sure it can accommodate the full length of the winch and
the bow roller, with a maximum of 2.54cm (1”) between
the two.
NOTE: If in doubt about the suitable construction of
a mounting pad or location consult a qualified marine
engineer. The deck/pad is an integral component of
the winch’s mounting; it must secure the winch and
bow roller and be strong enough to cope with the high
stresses involved in recovering the anchor.
Operational Specifications
Maximum Line
Speed
Maximum Tackle
Weight
Maximum Pull*
Product
Weight
3 m/minute
(75 ft/minute)
40 kg
(88 lbs)
100 kg
(220 lbs)
15 kg
(33 lbs)
NOTE: *Maximum Pull refers to the maximum amount of weight the winch can experience for ONLY short bursts while
breaking the anchor free from the bottom of the bed of water.
Rope Specifications
The winch comes equipped with 28.04m (92’) of 8mm
(0.3”) rope and 2m (6 ½’) of setting chain.
ONLY LEWMAR-SUPPLIED REPLACEMENT ROPE
KITS ARE COMPATIBLE WITH THIS PRODUCT. DO
NOT USE OTHER ROPE KITS OR THE AUTO-STOP
FEATURE WILL NOT FUNCTION CAUSING DAMAGE
TO THE UNIT.
