Lexico
n, Inc
.
DC-
2/MC-
1 Serial Com
muni
cations
Protocol
Printe
d on: 10/19/
00
37 of 44
10
Appendix B Error Codes
Error
Cod
e(Hex)
NO_ACK
0x00
DC_NO_ERROR
0x01
DC_ERR_PARITY
0x02
DC_ERR_FRAMING
0x03
DC_ERR_OVERRUN
0x04
DC_ERR_INVALID_PACKET
0x05
DC_ERR_TIME_OUT
0x06
DC_ERR_BUFFER_FULL
0x07
DC_INVALID_COUNT
0x10
DC_INVALID_CMD
0x11
DC_INVALID_DATA
0x
12
DC_INVALID_ADDRESS
0x13
DC_INVALID_EFFECT_ID
0x14
DC_INVALID_PARAM_ID
0x15
DC_INVALID_NAME 0x16
DC_INVALID_INPUT
0x
17
36
38
Table of Contents
Default Chapter
2
Table of Contents
2
1 Documents
4
2 Definitions
4
3 Abbreviations
4
4 General Description
4
5 Physical Layer
5
DB-9 RS232 Connector
5
Serial Port Driver
5
Errors
6
DC-2/MC-1 Receive Buffer
6
DC-2/MC-1 Hardware Verification
6
6 Data Link Layer
6
7 Application Layer
7
Errors
7
DC-2/MC-1 Asynchronous Notification Packets
7
Wakeup Notification
7
Sleep Notification
8
Front Panel Display Buffer
8
Parameter Change Notification
9
Acknowledgment Packets
10
Acknowledge
10
No Acknowledge
10
Host Initiated Command Packets
11
Reset Unit
11
Restore Defaults
11
Send IR Command
11
Get DC-2/MC-1 Unit Configuration
12
Get System Status
14
Get Record/Zone 2 Status
15
Get System Parameter Definition
16
Get System Parameter Values
18
Get Effect Definition by ID
18
Get Effect Parameter Definition
19
Get Effect Parameter Values
20
Get Custom Name
21
Get Input Name by ID
21
Get FPD Control Registers
22
Set System Parameter Values
23
Set Effect Parameter Values
23
Set Effect Name by Effect ID
24
Set System Volume
25
Set Main Balance
25
Set Front/Back Balance
26
Set Active Effect by ID
26
Set Record/Zone2 Input
27
Clear Record/Zone2 Input
27
Set Zone2 Volume
28
Set Zone2 Left/Right Balance
28
Set Custom Name
28
Set Input Name by ID
29
Set FPD Control Registers
30
Host Wakeup
30
Host Sleep
31
Get Communication Configuration
31
Set Communication Configuration
32
Set Mute
32
Set Output Level Adjustments
33
Send Display String Command
34
9 Appendix A Command Codes
35
8 Internal Use
35
Debug Character
35
PEEK Command
35
POKE Command
35
10 Appendix B Error Codes
37
11 Appendix C DC-2/MC-1 IR-Codes
38
12 Appendix D Input ID's
39
13 Appendix E Protocol Constants
39
14 Appendix F FPD Control Registers
40
15 Application Notes and Examples
40
Box Initializations
40
DC-2/MC-1
40
Host
40
Getting System Wide Status and Setup
41
Downloading the System Setup to the DC-2/MC-1
41
Simple System Control & System Status
41
Examples
42
Get Unit Configuration
42
Get Effect Definition
43
Set Input Name
43
Send IR Command Example
44
