1-1
Installing the LXP-5
1. Installing the LXP-5
Unpacking
After unpacking the LXP-5, save all packing materials in case you ever need
to ship the unit. Thoroughly inspect the LXP-5 and packing materials for
signs of damage. Report any shipment damage to the carrier at once. The
following accessories are included with the LXP-5:
1. Quick Reference card
2. Owner's Manual
3. Power pack (USA Part # 470-07345)
4. Warranty card (USA only)
Power
Connect the LXP-5 power pack to an appropriate AC wall socket, and the
cable end to the LXP-5 power connector. The LXP-5 must be used only with
the supplied power pack. Voltage requirements are printed on the power
pack. The LXP-5 has no power switch – it can be left on all the time. To keep
the power plug from working loose from the rear of the unit during transport,
you may wish to apply a small amount of silicone sealer to the plug after
inserting it.
Mounting
The LXP-5 measures 8.5"W x 1.7"H x 9.5"d (215.9 x 43.2 x 241.3 mm). The
optional rack mounting kit (A-LXP-R) handles one or two units in a single
rack space. Whatever mounting method you use, make sure that the LXP-
5 is securely screwed into the rack adapter – "friction fit" or double-stick tape
installations may allow units to loosen during transportation, resulting in
damage.
The maximum ambient operating temperature is 35°C (95°F). Provide
adequate ventilation if the LXP-5 is mounted in a closed rack with heat-
producing equipment such as synthesizer modules, effects units, or power
amplifiers. Avoid mounting the LXP-5 directly above power amplifiers.
