MIDI Implementation Data
4. MIDI Implementation Data
The information contained in this chapter is intended to assist experienced
programmers in developing software for use with the LXP-5.
LXP-5 System Exclusive (SysEx) implementation can be divided into two
basic categories: Data and Event Requests, and Data Transmit and Re-
ceive.
Data and Event Requests
Data Requests prompt the LXP-5 to transmit specified data. Event Requests
prompt the LXP-5 to store the data currently in the edit buffer to a specific
memory location (register), or to retrieve stored data and place it in the edit
buffer.
Data Requests
Byte Value Description
0 F0 (hex) System Exclusive
1 06 Lexicon ID
2 05 LXP-5 ID
3 0011 nnnn(bin) n = MIDI Channel 0-15
4 0eee eeee e =event code:
60h = active setup data
61h = one register
62h = param data
64h = all registers
5 0ppp pppp p = register number 0 - 127 for e = 61
= param number for e = 62, e = 65
above; else present but ignored
6 F7 (hex) End of SysEx message
