LXP-5 Owner's Manual
Footswitch operation
When a footswitch (optional) is connected to the rear panel FOOTSWITCH
connector, four user programmable functions are available. These functions
are selected by turning FUNCTION to EDIT B , SELECT to 15 and ADJUST
to one of the positions shown on the following table.
FUNCTION
EDIT B
ADJUST
MIN-4
5-8
9-12
13-MAX
Footswitch Function
Defeat Input
Defeat Output
Bypass
Memory Increment
SELECT
15
A push on/push off footswitch is useful for the Defeat and Bypass functions;
a momentary type footswitch should be used for the Memory Increment
function.
Defeat Input, Defeat Output and Bypass all affect the wet signal output of the
digital signal processor (DSP) only. The dry signal, as set by the front panel
MIX control, is unaffected.
Defeat Input mutes the input to the DSP, allowing the effect the decay
naturally to silence.
Defeat Output mutes the effect output quickly.
Bypass alters the DSP program so that the effect is also dry.
If programs or parameters are changed while Defeat or Bypass is activated,
the effect will assume the new values when Defeat or Bypass is released.
If no changes are made, the wet sound will return to its original settings.
