4-10
LXP-5 Owner's Manual
Knob Mechanism Parameters
27 Delay 1 Fine Edit Knob
28 Reserved
29 Delay 2 Coarse Edit Knob
30 Delay 2 Fine Edit Knob
Param # Description
23 Delay 0 Coarse Edit Knob
24 Delay 0 Fine Edit Knob
25 Reserved
26 Delay 1 Coarse Edit Knob
Delay Parameters
Parameter # Range: Increment Resolution
Pitch/Delay Delay/Reverb
Delay 1 - Coarse 0 0 - 1.0404 sec 0 - 630.8 msec ≈ 8.2 msec 128 steps P/D
78 steps D/R
Provides a coarse adjustment of mono delay time.
Delay 1 - Fine 1 0 - 8.1 msec 0 - 8.1 msec 64 usec 128 steps
Function: Provides a fine adjustment of mono delay time by adding to the Delay 1-Coarse
value.
Feedback 1 2 0 - 100% 0 - 100% ≈ 0.79% 128 steps
Adjusts positive feedback around the mono delay. In Pitch/Delay, 100% feedback automati-
cally cuts the input, and can be used as a manual, or MIDI controlled, delay line sampler. In
Delay/Reverb, 100% feedback does not cut the input, but continues to add it in. There is also
a slight high frequency rolloff through the gliding delay mechanism of Delay/Reverb-Delay 1.
Delay 2 - Coarse 3 0 - 322.5 msec 0 - 176.6 msec 2.56 msec 127 steps P/D
70 steps D/R
Provides a coarse adjustment of two-channel delay time.In Delay/Reverb, provides a pre-
delay adjustment for the reverb. In Pitch/Delay provides a reverb pre-delay and adjusts the
right channel.
Delay 2 - Fine 4 0 - 2.5 msec 0 - 2.5 msec ≈ 20 usec 128 steps
Provides a fine adjustment of right channel delay time by adding to the Delay 2-Coarse value.
Feedback 2 5 0 - 99% NA ≈ 0.79% 127 steps
Adjusts feedback around the pitch shifter and left channel delay.
Delay 3 - Coarse 6 0 - 322.5 msec NA 2.56 msec 127 steps
Provides a coarse adjustment for left channel delay.
Delay 3 - Fine 7 0 - 2.5 msec NA ≈. 20 usec 128 steps
Provides a fine adjustment for left channel delay by adding to the Delay 3-Coarse value.
