4-7
MIDI Implementation Data
Parameter Map
Param # Data
0 - 22 Microcode Parameters
23 - 30* Knob Mechanism Parameters
31 - 41 Name (11 characters)
42 Reserved
43 Adjust Knob Patch Destination (microcode param # 0 - 22)
44 - 48 MIDI General Purpose Patch 1 (see below)
49 - 53 MIDI General Purpose Patch 2 (see below)
54 - 58 MIDI General Purpose Patch 3 (see below)
59 - 63 MIDI General Purpose Patch 4 (see below)
64* Memory location (0 - 127)
65* Preset # (0 - 65; 0-63=Preset Table, 64=Bypass,
65=Edit buffer, 127=Memory location)
66 Algorithm ID (1 - 3; 1=Delay/Reverb, 2=Pitch/Delay, 3=Bypass)
67* Footswitch Mode (0 - 127; 0 & 4-127=Defeat Input, 1=Defeat Output,
2=Bypass, 3=Memory Increment)
68* Memory Write Protect (nonzero = write protected)
69 Global Patch Enable (0=global patches disabled, 1=global patches
ignored on setup recall until Source controller is moved,
2=global patches active immediately on setup recall
70 - 92* MIDI Global Patch Sources
*Not stored during program save.
General Purpose Patch Parameter Map:
Param #
Patch 1 Patch 2 Patch 3 Patch 4 Data
44 49 54 59 Patch Source
(0 - 127, see below)
45 50 55 60 Patch Threshold
(0 - 127)
46 51 56 61 Patch Destination
(microcode param # 0-22)
47 52 57 62 Patch Scale Factor
(-64 to +64, 2’s complem.)
48 53 58 63 Patch Offset
