45D0028 31
CLEANING AND MAINTENANCE
Clean the ceramic glass periodically. Condensation will sometimes form on the glass during a cold startup. This is normal
for all gas replaces and stoves. This condensation often attracts dust and lint to the surface of the glass. The initial paint
curing of the appliance can also leave a slight lm on the glass. This is a temporary problem.
Your should clean the glass after the rst two weeks of use. After that, you should clean the glass no more than two or three times
a season. Use a mild glass cleaner to clean the door. Do not use abrasive cleaners. They will damage the glass surface.
PILOT AND BURNER FLAMES
Visually check pilot and burner ames periodically. See Figure 43 for typical burner ame. See Figure 44 for typical
pilot ame.
Let glass cool before cleaning. Do not
clean glass when it is hot. Damage
could occur.
CAUTION
Make sure the gas valve knob is in the “OFF” position. Wait at least five (5) minutes before start-
ing maintenance.
VENTING SYSTEM
A qualied agency should examine the venting system annually.
CLEANING GLASS
Make sure clearances to combustibles
leave room for maintenance and
service.
WARNING
Carefully reassemble and reseal
stove properly after any cleaning or
servicing.
WARNING
FIREBOX CLEANING
1. Carefully remove grate, log set, and embers from com-
bustion chamber.
2. Vacuum burner compartment thoroughly.
3. Vacuum any dust off logs.
4. Remove any lint from main burner and pilot.
5. Carefully replace grate, log set, and embers in their
correct positions. See pages 25 through 27.
6. Replace door (if it has been removed).
7. Relight pilot. See page 28.
8. Turn on main burner.
Figure 43 - Typical Burner Flame
Figure 44 - Typical Pilot Flame
Thermopile
Thermocouple
