8 45D0028
The dimensions shown in Figures 4 and 5 are minimum clearances to maintain in
installing this heater. Left and right clearances are determined when facing the front
of the heater.
Follow these instructions carefully to ensure safe installation. Failure to follow
instructions exactly can create a fire hazard.
The appliance cannot be installed on a carpet, tile or other combustible material other
than wood flooring. If installed on carpet or vinyl flooring, the appliance shall be installed
on a metal, wood or noncombustible material panel extending full width and depth of
the appliance.
WARNING
CLEARANCES
Figure 4 - Clearances to Side, Back and Adjacent Walls
(C28/C40)
CLEARANCES TO COMBUSTIBLES
Figure 5 - Clearance to Floor (C28/40)
Maintain the following minimum clearances for service and maintenance.
• Stove must be at least 6" from the back wall and either side wall. See Figure 4.
• Stove must be at least 4" from the corner. See Figure 4.
• No clearance is necessary to the oor. Stove may sit on the oor. See Figure 5.
• The minimum ceiling height from the oor must be 72".
