Area Area name Jam numbers What to do
12 Door B 230 Open door B, and then remove jammed paper.
13 Door A 201–202
231
281
Open door A, and then remove the jammed paper.
Remove all jammed paper in the fuser.
14 Door D 203 Open door A, and then door D, and then remove the jammed paper.
201–202 paper jams
If the jammed paper is visible in the standard exit bin, then firmly grasp the paper on each side, and then gently pull it
out.
Note: Make sure all paper fragments are removed.
Paper jam in the fuser
1 Open door A by lifting the release latch and lowering the door.
CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching.
2 Pull the green lever down.
2
1
Clearing jams 275
