Lexmark 7014-431 - Door Mount Removal

Repair information 4-17
7014-xxx
Door mount removal
1. Open the front cover.
2. Remove the lower front cover. See “Lower front cover removal” on page 4-35.
3. Remove the left side cover. See “Left side cover removal” on page 4-33.
4. Remove the right side cover. See “Right side cover removal” on page 4-77.
5. Remove the cable through the opening.
6. Remove the three screws (A) from the right side of the printer.
A
