Lexmark 7014-431 - Right Side Cover Removal

Repair information 4-77
7014-xxx
Right side cover removal
Note: Leave the front cover closed when removing the right side cover assembly.
1. Remove the scanner front cover. See “Scanner front cover removal” on page 4-31.
2. Remove the plastic screw (A) securing the cover to the tub assembly.
3. Remove the screw (B) from the bottom right side of the printer.
A
B
