Lexmark E352DN User Manual

Adding a flash memory card
32
Installing options
Adding a flash memory card
Note: Flash memory card options designed for other Lexmark printers may not work with your printer.
1 Access the system board (see Accessing the system
board on page28).
2 Unpack the flash memory card.
Note: There are two sets of holes on the system
board for flash memory card installation.
The flash memory card may be installed into
either set of holes, however, only one flash
memory card may be installed.
Warning: Flash memory is easily damaged by static
electricity. Touch something metal, such as
the printer frame, before you touch a flash
memory card.
Avoid touching the metal connection points on the connector.
3 Squeeze the retainers, and align the plastic pins on the flash memory card with the holes on the system board.
4 Push the flash memory card firmly into the holes of the system board until it snaps into place.
5 Close the side access door.
6 Close the rear exit door.
7 Close the front door.
8 Plug the power cord into the wall outlet and turn the printer on to continue print functions.
CAUTION: If you are installing a flash memory card after setting up the printer, turn the printer
off, and unplug the power cord from the wall outlet before continuing.

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
