Lexmark M5270 Service Manual

Action Yes No
Step 11
Reinstall or replace the door. See
“Staple finisher rear door
removal” on page 582.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 12
Make sure that the controller board of the aected optional bin is
properly installed. Reseat all the cables on the controller board.
Does the problem remain?
Go to step 13. The problem is
solved.
Step 13
Check the aected controller board and its connector pins for
damage.
Are the bin controller board and its connectors free of damage?
Contact the next
level of support.
Go to step 14.
Step 14
Replace the bin controller board. See
“Staple finisher controller
board removal” on page 590.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Sensor (staple finisher pass‑through) early‑ or late‑arriving jam service check
Action Yes No
Step 1
Make sure that all the optional bins are properly installed.
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
Open all optional bin doors, and then check the paper path and
bins for paper fragments and partially fed paper.
Is the paper path free of paper fragments and partially fed paper?
Go to step 4. Go to step 3.
Step 3
Remove the paper fragments and partially fed paper.
Does the problem remain?
Go to step 4. The problem is
solved.
Step 4
Clear the optional bin paper path rollers of any dirt and
contamination.
Does the problem remain?
Go to step 5. The problem is
solved.
4064
Diagnostics and troubleshooting
222

Lexmark M5270 Specifications

General

Print Resolution	1200 x 1200 dpi
Processor Speed	1.2 GHz
Print Technology	Laser
Standard Memory	1 GB
Maximum Memory	4 GB
Standard Input Capacity	550 sheets
Connectivity	Ethernet, USB, Wireless
Hard Disk	Option available
Recommended Monthly Page Volume	5, 000 to 50, 000 pages
Network Protocol	TCP/IP, IPv4, IPv6
Printable Area	8.5 x 14 inches
Paper Handling Input, Standard	550 sheets
Paper Handling Output, Standard	250 sheets
Media Types Supported	Card Stock, Envelopes, Paper Labels, Plain Paper, Transparencies
Media Sizes Supported	Letter, Legal, Executive, A4, A5, B5, Envelopes
Standard Ports	USB 2.0, Gigabit Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Linux, Mac OS X
Duplex Printing	Standard
