Lexmark M5270 Service Manual

Margin Oset
This setting allows you to adjust the margin
oset
and to print or reset the default settings.
For non-touch-screen printer models, press
to navigate through the settings.
1 Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Margin Oset
2 Select a setting.
Universal Override
This setting allows the user to feed custom media sizes to a Custom Media Tray.
For non-touch-screen printer models, press
to navigate through the settings.
1 Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Universal Override
2 Select a setting to adjust.
Additional input tray diagnostics
Sensor tests
For non-touch-screen printer models, press to navigate through the settings.
1 Enter the Diagnostics menu, and then touch Additional input tray diagnostics.
2 From the Sensor tests section, touch Start.
A dialog listing the sensor tests appears.
3 Find, and then manually toggle the sensor.
Notes:
• The sensor status on the screen toggles between 1 and 0 when the sensor is properly working.
• If a sensor test fails, the test failure may not indicate a failed sensor. Further troubleshooting may be
required. Check the boards and cables for possible issues.
List of sensor tests
Pick roller index (tray [x])
Media out (tray [x])
Pass‑through (tray [x])
Media size (tray [x]) switch [x]
Pick (tray [x])
4064
Service menus
385

Lexmark M5270 Specifications

General

Print Resolution	1200 x 1200 dpi
Processor Speed	1.2 GHz
Print Technology	Laser
Standard Memory	1 GB
Maximum Memory	4 GB
Standard Input Capacity	550 sheets
Connectivity	Ethernet, USB, Wireless
Hard Disk	Option available
Recommended Monthly Page Volume	5, 000 to 50, 000 pages
Network Protocol	TCP/IP, IPv4, IPv6
Printable Area	8.5 x 14 inches
Paper Handling Input, Standard	550 sheets
Paper Handling Output, Standard	250 sheets
Media Types Supported	Card Stock, Envelopes, Paper Labels, Plain Paper, Transparencies
Media Sizes Supported	Letter, Legal, Executive, A4, A5, B5, Envelopes
Standard Ports	USB 2.0, Gigabit Ethernet
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Linux, Mac OS X
Duplex Printing	Standard
