Lexmark MS315 - Page 227

6 Remove the duplex. See “Duplex removal” on page 218.
7 Use a small flat-head screwdriver to block the roller (A) and prevent the shaft from rotating.
8 While blocking the roller, remove the screw (B).
B A
9 Pull out the ACM clutch, and leave it hanging.
4514
Repair information
227
