B. Collecting the firmware logs (Fwdebug and logs.tar.gz) from the SE menu
Notes:
Make sure that your printer is connected to a network or to a print server.
Some printers are designed to restart automatically after a 9yy error. On these printers, you can retrieve
the secondary crash code information using the SE menu.
1 Open a web browser, type http://printer_IP_address/se, and then press Enter.
2 Click Logs Gzip Compressed.
Note: A logs.tar.gz file is saved to the Downloads folder. The file may take several minutes to save. You
may rename the file if a logs.tar.gz already exists in the Downloads folder.
3 E-mail the logs to your next level of support.
Note: To download the FWdebug log to a
flash
drive, see
“General SE” on page 150.
C. Collecting the settings from the Menu Settings Page
Note: The Menu Settings Page is
dierent
for each printer. For more information, see the User’s Guide. Your
next level of support will tell you which page they want to see.
Copying the Menu Settings Page from the Embedded Web Server (EWS)
Note: Make sure that your printer is connected to a network or to a print server.
1 Open a web browser, type http://printer_IP_address, and then press Enter.
2 Click Settings, and then select one of the settings pages from the links shown on the page.
3 Copy all the information, and then save it as a text
file.
4 E-mail the text
file
to your next level of support.
Printing the Menu Settings Page
1 From the home screen, navigate to:
Reports > Menu Settings Page
2 Print the Menu Settings Page, and then use Scan to E-mail to send it to your next level of support.
D. Collecting information from the user
Ask the user for information about the following:
Print job being run
Operating system being used
Print driver being used
Other information on what was happening when the 9yy error occurred
4600-830, -835, -895
Diagnostics and troubleshooting
131

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark MS621dn and is the answer not in the manual?

Lexmark MS621dn Specifications

General IconGeneral
DisplayLCD
CertificationICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN / CSA-C22.2 60950-1, NOM, CB EN / IEC 60950-1 , CB EN / IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN / IEC 60950-1, CE EN / IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024 , UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC1275, MET-I, ISO 532B, ECMA-370, TED, GOST -R, SII, TER
Product colorAnthracite, White
Built-in displayYes
Display diagonal2.4 \
Market positioningEnterprise
Power consumption (off)0.1 W
Power consumption (ready)9.5 W
Power consumption (standby)2.2 W
Power consumption (printing)670 W
Energy Star Typical Electricity Consumption (TEC)2.1 kWh/week
Print technologyLaser
Time to first page (black, normal)6 s
Print speed (black, normal quality, A4/US Letter)50 ppm
Duplex print speed (black, normal quality, A4/US Letter)24 ppm
Printing colorsBlack
Country of originChina
Maximum duty cycle175000 pages per month
Recommended duty cycle2000 - 20000 pages per month
Number of print cartridges1
Page description languagesMicrosoft XPS, PCL 5e, PDF 1.7, PPDS, PostScript 3
Processor cores2
Processor frequency1000 MHz
Sound power level (standby)14 dB
Sound pressure level (printing)56 dB
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supportedFedora 23, Fedora 24, Fedora 25, Fedora 26, Fedora 27, Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, openSUSE 13.2, openSUSE 42.3
Other operating systems supportedNovell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server, Novell Open Enterprise Server 11, Novell Open Enterprise Server 2
Server operating systems supportedSUSE Linux Enterprise Server 10, SUSE Linux Enterprise Server 11, SUSE Linux Enterprise Server 12
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Total input capacity650 sheets
Total output capacity250 sheets
Maximum input capacity2300 sheets
Maximum number of input trays5
Envelopes sizes7 3/4, 9, 10, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Multi-purpose tray media typesEnvelopes, Plain paper, Transparencies
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 216 g/m²
Sustainability certificatesENERGY STAR
Operating altitude0 - 5000 m
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Package depth470 mm
Package width430 mm
Package height422 mm
Package weight17760 g
Cabling technology10/100/1000Base-T(X)
Security algorithms802.1x RADIUS, HTTPS, LEAP, MD5, MSCHAPv2, PEAP, SSH, SSL/TLS, TTLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint
Supported network protocols (IPv4)TCP/IP IPv6, TCP/IP IPv4, AppleTalk, TCP, UDP
Cables includedAC
USB connectorUSB Type-A / USB Type-B
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Weight and Dimensions IconWeight and Dimensions
Depth374 mm
Width399 mm
Height303 mm
