Lexmark MS621dn

D
C
MPF gearbox removal
1 Remove the front door. See “MPF with front access cover removal” on page 201.
2 Remove the left cover. See “Left cover removal” on page 177.
3 Remove the main drive gearbox. See “Main drive gearbox removal” on page 178.
4 Disconnect the spring (A).
4600-830, -835, -895
Parts removal
179
