Lexmark MS621dn

3 Release the three latches (B), and then pry to remove the sensor.
B
A
B
Cooling fan removal
MS621 cooling fan
1 Remove the right cover. See “Right cover removal” on page 186.
2 Disconnect the cable JFAN1 from the controller board.
4600-830, -835, -895
Parts removal
190
